Atoll Electronique AM300

Main features:

6 MOS-FET transistors per channel

2 × 150W rms / 8Ω

Balanced XLR input

2×440 VA Power supply

Double mono integral structure

Symmetrical stages with discrete components polarized in
Class A/B Audio stages stabilized in current by a proprietary system

CONNECTIONS AND CONTROLS

Audio inputs:
1 stereo Line input 1 stereo XLR input

Audio outputs:
1 stereo Line output
1 stereo speaker output

1 12 V Trigger input
1 bridged-mono switch 1 Line/XLR selector

TECHNICAL DATA

Power Wrms/ch./8 Ω: 150 W
Power Wrms/ch./4 Ω: 280 W
Power in bridged mono/8 Ω mode: 500 W
Power Supply: 880 VA
Total of capacitors: 83 300 μF
Output Impedance: 220 k Ω
Sensitivity: 1,7 V
Signal/Noise Ratio: 1 00 dB
Distorsion at 1 kHz: 0,005%
Bandwidth: 5 Hz – 200 kHz
Rising time: 1,5 μs
Dimensions: 440 x 360 x 103mm
Weight: 19,0 Kg

Available in black or silver
