LIMITED EDITION
The Klipsch + OJAS kO-R2 is a strictly limited edition. The unparalleled uniqueness of this product and the innovative collaboration between Klipsch and OJAS have generated demand that exceeds our inventory. Secure your piece of audio history today, before they vanish into history.
LEGENDARY PEDIGREE
Handcrafted in Hope, Arkansas, USA by skilled Klipsch artisans, the kO-R2 exemplifies nearly a century of speaker-building expertise, delivering a meticulously built loudspeaker of unparalleled quality.
BUILT TO STUN
The kO-R2 epitomizes OJAS’s visionary design philosophy, incorporating bespoke materials such as an exposed sandcast aluminum multisectoral horn and Baltic birch plywood with full butt joint construction. Available in spiral red oak veneer or hammertone finishes with a matte black horn.
TECH DELIGHTERS
Embodying a minimalist ethos, the kO-R2 features bespoke materials and cuttingedge components, anodized aluminum binding posts, and anti-vibration rubber feet. A laser-engraved metal ID plate adds a touch of exclusivity, while a five-step high-frequency gain attenuator provides precise sound tuning.
SPECIFICATIONS
| FREQUENCY RESPONSE¹ | 39 Hz-20kHz +/-3dB |
| FREQUENCY RESPONSE (-10dB) | 29 Hz-21kHz -10dB |
| POWER HANDLING² | 300W (34.6V) 40 Hz-10kHz |
| CALCULATED MAX. CONTINUOUS OUTPUT³ | 118dB 40 Hz-10kHz |
| SENSITIVITY⁴ | 97 dB @ 2.83V |
| CROSSOVER POINT | 760 Hz |
| HORIZONTAL COVERAGE PATTERN | 90 degrees, +/- 30 degrees, 500Hz to 20kHz |
| VERTICAL COVERAGE PATTERN | 70 degrees, +/- 20 degrees, 3kHz to 20kHz |
| NOMINAL IMPEDANCE | 8 ohm (4.2 ohm min. @ 100 Hz) |
| TRANSDUCERS | K-33-E 15″ Woofer, K-706 HF Driver |
| ENCLOSURES | vented system |
| ENCLOSURE MATERIAL | 13-ply Grade A Baltic Birch Plywood |
| TERMINALS | 5 way binding posts |
| DIMENSIONS |
25.375″ (64.45cm) W x 45.5″ (115.5cm) H x 22.25″ (56.5cm) D
|
| NET WEIGHT | 120.5 lbs. (54.65kg) |
| SHIPPING WEIGHT | 134 lbs (60.78kg) |
¹ 3M, Half-space anechoic
² AES standard continuous pink noise 6dB peaks
³ Calculated at 1M half-spaced at power handling power input
⁴ SPL at 1M, half-spaced anechoic with 2.83 volts input
