AVM Audio PAS 30.3

AVM 30.3: Preamp with Streaming Functionality

Our AVM 30.3 Neo classics in the tradition of our preamps are the modern interpretation of the amplifiers that have been developed uncompromisingly since the early 1990s. Based on the AVM X-STREAM engine®, the new PAS 30.3 preamplifier has been created. Numerous new features have been incorporated and the new RC X APP also controls the PAS 30.3 completely. There is no need for towers of appliances and overflowing cable clutter, and all modern connections are available, so that even a TV can be connected via HDMI ARC. In order to construct one of the most powerful sound in its class, we have miniaturized proven sound technologies and designed them into a compact and slim precision housing.

The main focus was on a completely modernized APP control, the RC X app clearly contains all important functions. The simplest, intuitively learnable operation as well as a clear and nicely designed user interface make the management of even large music collections child’s play. This makes you want to explore new music on numerous streaming platforms. The AVM RC X app is available for iOS (Apple) or Android-controlled devices.

The new AVM X-STREAM engine® can stream all high-resolution formats, including DSD (256). This streaming engine is a complete AVM in-house development and is completely software-based, so it can be updated online in a future-proof manner. An HDMI (ARC) interface is also on board as well as the modern Bluetooth connection, further digital inputs and also a USB A interface are standard. Special attention has been paid to the phono input stage for MM and MC.

This high-precision input stage has been completely redesigned for installation in the compact PAS 30.3. This ensures even better sound, especially in combination with our rotation turntables. Completely new are the digital outputs, which can also be volume controlled. The HDMI ARC input can also be used to easily connect and conveniently control TV sets.

The PAS 30.3 has also made a huge leap in terms of sound. This technological leap is based on the use of AVM amplifier technologies, which we have been constantly refining since the 80s. With its numerous connection options, the PAS 30.3 is prepared for practically any application.



Specifications:

Pre-Amp (Pre-Out)

Input resistance 3.4 kΩ
Output resistance 470 Ω
Amplification Factor 1
THD < 0.001%
Signal-to-noise ratio > 100dB
Frequency response (at -3dB) < 5Hz to > 80kHz
Crosstalk Attenuation (Channels) > 95dB
Crosstalk attenuation (inputs) > 85dB
Input Output (1% THD) V
Output Output (1% THD) V

Pre-Amp (Line-Out)

Output resistance 47 Ω
Amplification Factor 1
THD < 0.001%
Signal-to-noise ratio > 100dB
Output Output (1% THD) V

Pre-Amp (Headphone-Out)

Output resistance 80 Ω
Amplification factor 4
THD < 0.001%
Signal-to-noise ratio > 100dB
Output Output (1% THD) V

Preamp (Phono)

Equalization RIAA < 0.2dB
Gain MM 40dB
Signal-to-noise ratio MM > 83dB(A)
Gain MC 60dB
Signal-to-noise ratio MC >74dB(A)
Input control MM (1% THD) mV
Input control MC (1% THD) mV

Network

LAN connection (hot-plugging capable) 100Mbit/s
Supported WLAN/ Wifi standards 2.4 / 5 GHz 802.11a/b/g/n/ac
Number of antennas 2
WPS yes

Streaming

Max. sample rates DSD256, 32Bit/384kHz PCM
Streaming Services AirPlay, Qobuz, Roon Ready, Spotify, TIDAL, HighResAudio
Supported file formats: WAV, MP3, WM, AAC, FLAC, ALAC, DSD, Ogg, AIFF

Bluetooth

Bluetooth standard 5.0 LE
Supported Bluetooth Profiles AVRCP 1.5 AD2P
USB Input (Rear)
USB standard USB 2.0
Max. current 500 mA
Supported formatting FAT16, FAT 32, NTFS

ATTENTION: The USB input is only intended for hard drives and USB sticks!

Digital Inputs (S/P-DIF/ Coaxial)

Max. Sampling/Bitrate (OPTO) 96 kHz / 24 Bit
Deemphasis (OPTO) Yes, automatically
Max. Sampling/Bit Rate (COAX) 192 kHz / 24 Bit
Min. signal level [Vpp] at 195kHz (COAX) > 150 mVpp
Input Impedance (COAX) 75 Ω
Deemphasis (OPTO) Yes, automatically
Max. Sampling/Bitrate (ARC) 192 kHz / 24 Bit
Input Impedance 100 Ω

NOTE: When using the digital inputs, the cable length of the digital cables should not exceed three meters.

Digital Outputs (S/P-DIF / Coaxial)

Max. Sampling/Bitrate (OPTO) 96 kHz / 24 Bit
Max. Sampling/Bit Rate (COAX) 192 kHz / 24 Bit
Output Impedance (COAX) 75 Ω

NOTE: When using the digital outputs, the cable length of the digital cables should not exceed three meters.

Power consumption

Standby < 0,5 Watt
Extended stand-by (network connection) < 2 watts
Idle < 16 Watts
Fuse used T 3.15A H

General

Weight 6.9 kg
Dimensions (WxHxD) 430 x 115 x 355
Warranty 2 years (+2 years if you register online*)

*Warranty periods may vary from country to country.
