OPEN SOUNDSTAGE FROM SLIM-LINE SPEAKER
The focus of any great loudspeaker is to produce an open, ‘being there’ sound and the Q 3010i do just that despite their compact size. Boasting room-filling sound with its 100mm (4 in) and 22mm (0.9 in) precision drivers, focussing on power-to-size ratio, the crossover has been revised to take advantage of a larger cabinet volume to enhance sensitivity and bass extension. The Q 3010i speakers can be shelf-mounted on compliant, pre-fitted rubber feet, stand-mounted or wall-mounted on optional, dedicated stands and brackets.
INCREASED CABINET SIZE DELIVERING A BOLDER SOUND
The 3010i maintain the same acoustically optimal front profile, but have been made slightly taller and 25% deeper than previous models. This increased internal volume has enabled Q Acoustics to gain an extended low frequency response from the ported design so that more-than-ever the smaller enclosures in the range belie their diminutive stature with an impressively large-scale sound. As an added benefit, the enlarged front-to-back dimension means that any cone- generated noise reflected from the back wall of the enclosure and out through the cone itself is reduced.
Specifications:
Enclosure type: 2-way reflex
Bass Unit: 100 mm (4 in)
Treble Unit: 22 mm (0.9 in)
Frequency Response (+3 dB, -6 dB): 65 Hz – 30 kHz
Nominal Impedance: 6 Ω
Minimum Impedance: 4 Ω
Sensitivity (2.83 Vrms@1 m): 86 dB
Stereo Amplifier Power: 15 – 75w
AV Receiver (2 ch. driven): 50 – 125 W
Crossover Frequency: 2.6kHz
Effective Volume: 4.0 L (244 cu in)
Dimensions H/W/D: 253 x 150 x 252 mm (10.0 x 5.9 x 10 in)
Weight (per speaker): 4.1 kg (9.0 lbs)
What’s in the box?
2 x 3010i bookshelf speakers
2 x Foam Bungs
2 x Speaker Grilles
1 x User Manual
1 x Handling Gloves.
8 x Rubber Speaker Grips
