We took the award winning S/5 SHO, and reduced, only slightly, the size and power to better suit more modest systems and rooms, retaining all the majestic beauty and innovative engineering found in its larger sibling.
Power and Performance
THE BEAUTIFULLY BALANCED S/3 SHO
S/3 SHO (Super High Output) derives from the flagship S/5 SHO offering a more compact footprint while retaining much of S/5 SHO’s performance, making it an ideal pairing for slightly more modest systems and rooms. In quality it is the equal of S/5 SHO using the same Continuous CastTM Alloy Cone Driver and carbon passive radiator, only in a slightly reduced size, paired with a 400W NexGen2 digital amplifier. Beautifully balanced, S/3 SHO offers powerful, incisive performance for both 2-channel and theater systems.
SHO refers to Super High Output, made possible by a new 3-stage limiter our engineers created after extensive testing revealed that much higher output, higher gain and higher performance could be unlocked. The result is a new design that is capable of more than doubling its predecessor’s output. Specify the S/3 SHO, singly or in pairs, when your system is of exceptionally high quality, and your speakers and room can support high levels of dynamics and bass extension.
Smooth Speed & Slam
CONTINUOUS CAST ALLOY BASS ENGINE
S/3 SHO’s driver features an all-new alloy cone structure that takes our mid-level product to a performance that exceeds our reference products of only a few years ago. By reducing moving mass, with a balanced approach to design, our engineering team was able to produce far more speed than prior designs. By carefully adjusting key parameters, we were able to increase the self-quieting key to a high-end component’s ability to resolve space and inner detail. Improvements in our designs translate into enhancement in your entire system.
Sound Beyond Its Size
CARBON PASSIVE RADIATOR
S/3 SHO uses a special carbon/carbon passive that is stiff, lightweight and incredibly well-behaved. Our approach to passive design results in performance more akin to a variable ratio driver size. On an S/3 SHO, think of it as a sliding ratio design wherein the S/3 SHO begins as an ultra-fast 10” sealed box design and, as more power and deeper bass is demanded S/3 SHO gradually morphs into the power and output of a 15” design.
Fast, Extended Lows
NEXTGEN2 400W DIGITAL AMPLIFIER
Beyond our proprietary drivers, the performance of a REL is determined by our unique input filters and amplifiers. REL S/3 SHO uses a simple filter-type that is very fast—about 8 milliseconds in group delay– to cross out unwanted higher frequencies to our driver. This speed and our carefully sorted filters allow for seamless blending of RELs with the main speakers. REL does not include a high pass filter to cross out bass from the main speaker because to do so would generally produce more unwanted effects than the minor benefits such a design confers.
S/3 SHO’s power amplifier is a powerful NextGen2 400W digital amplifier. This design has powered thousands of RELs and has proven exceptionally reliable and very fast with deep, extended lows—it provides a perfect mate to our new driver.
Freedom
LONGBOW™ WIRELESS CONNECTIVITY
LongBow permits very fast, uncompressed bass to be sent wirelessly within the same room approximately 45 feet (somewhat dependent upon room clutter). We have selected an un compressed format as it results in natural, quick delivery compared with conventional wi-fi or Bluetooth systems. Because it is a REL, we developed LongBow with both high level (or low level with crossover intact) AND .1 channel delivery so that REL Theatre Reference performance can be maintained even when using our wireless delivery system.
Specifications
TYPE
Front-firing active driver, down-firing passive
ACTIVE DRIVER SIZE & MATERIAL
10 in., 250mm long-throw, Continuous CastAlloy™ cone structure, cast chassis
PASSIVE RADIATOR SIZE & MATERIAL
12 in., 300mm Carbon/Carbon flat cone structure, steel chassis
LOW FREQUENCY EXTENTION
-6dB at 21 Hz
INPUT CONNECTORS
CONNECTORS High Level Neutrik Speakon, Low Level stereo RCA, LFE RCA, SMA for wireless antenna
OUTPUT CONNECTORS
N/A
POWER OUTPUT
400 watts (RMS)
AMPLIFIER TYPE
NextGen2 Class D
WIRELESS CAPABILITY
Longbow (Optional), Zero Compression, Individual discrete D/A and A/D Encoders
Protection System
FULLY ELECTRONIC SET SAFE
Yes
D.C. FAULT
Yes
OUTPUT SHORT
Yes
MAINS INPUT VOLTAGE
220-240 volts, 110-120 volts for certain markets
FUSES
5 Amp 220 volts operation, 9 Amp 120 volts operation
Dimensions
W X H X D
16 x 16.7 x 18.25 in. (406 x 424 x 463.5 mm)
NET WEIGHT
61.4 lbs. (27.85 kg)
FINISH
Piano Black Lacquer, White Lacquer, 8 coats
Supplied Accessories
MAINS LEAD
Yes
NEUTRIK SPEAKON
Yes (10 Meters Nominal)
INTERCONNECT
–
USERS MANUAL
Yes
